Specification
1. Impedance: 50 Ohm
2. V.S.W.R.(Return loss): 1.4(15.6dB) max, DC to 2GHz
3. Insertion loss: ≦0.3dB to 3GHz
4. Center contact resistance: ≦40 mOhm after 25 mating cycles
5. Outer contact resistance: ≦40 m Ohm after 25 mating cycles
6. Working voltage: 60 V dc
7. Current rating: 1 A dc
8. Fire protection grade: UL 94-V0
Compliance
Product is strictly developed in accordance with national standard requirements to meet market versatility.
1. ISO 20860-1 Road vehicles 50 ohms impedance radio frequency connection system interface –
Part 1: Dimensions and electrical requirements
2. ISO 20860-2 Road vehicles 50 ohms impedance radio frequency connection system interface –
Part 2: Test procedures
3. USCAR 17 Performance Specification for Automotive RF Connector Systems
4. USCAR 18 FAKRA SMB RF connector supplement
5. RoHS Compliant
Feature
1. Applicable impedance: 50 Ohm
2. Frequenc up to 6 GHz
3. A variety of applications: AM/FM Radio, GPS, Cellular/ PCS, WIFI, Bluetooth,Vehicle control, Satellite radio, Wireless remote
4. A variety of mounting structure and key type combination
Order information
Physical dimension
Key code option
